HDMI MATRIX CONTROLLER 04X04

Description

• Supports 4 HDMI inputs and 4 HDMI outputs; ports support HDMI1.4 and are HDCP compatible; also supports HDMI1.3a
• Input and output resolution support: 480p / 720p / 1080i / 1080P; supports DVD24/50/60fs, HD-DVD, xvYCC video formats
• HDMI input transmission distance up to 20 meters; output transmission distance up to 30 meters
• Supports 4 HDMI audio inputs and 1 HDMI audio output (Note: Only output port 10 of HDMI can be used as audio output); Audio formats: DTS-HD / Dolby TrueHD / LPCM7.1 / DTS / DOLBY-AC3 / DSD
• Supports HDTV resolutions including 1080/60 and PC resolution up to 1920x1200P
• Matrix bandwidth: 4.5Gbps
• FPGA programmable logic circuit supports free switching with quick response
• High-speed digital transmission helps reduce crosstalk and ghosting for cleaner output
• Built-in long line self-adaptive input compensation automatically compensates for signal loss
• Control options: RS232, remote controller, keyboard
• Power failure restart quickly restores the display state before power failure.
